RE-LOCK BLE from the official Re-Lock site

1 / 4

🔒 Smart Lock

Fleet Recommended

Re-Lock

RE-LOCK BLE

Name: RE-LOCK BLE
Brand: Re-Lock
SKU: RE-LOCK

Bluetooth smart lock for bike-sharing and rental fleets with a replaceable battery, ART approval, and support for tires up to 70 mm.

Capability Categories

Lock Only

Bluetooth

Locking / Access Summary

Unlock

Bluetooth

Power

Replaceable battery

Tire Fit

Up to 70 mm

Security

ART approved

Contact for Pricing Manufacturer Site

Technical Specifications

Access & Power

Open / Close

Bluetooth

Power Supply

Replaceable battery

Tire Fit

Fits around almost any tire up to 70 mm (cargo bikes, fat-tire e-bikes)

BLE PCB Technical Sheet

PCB Size

73.0 x 30.0 mm

Radio

Nordic nRF52832

Wireless

Bluetooth Low Energy 4.0 and proprietary 2.4GHz

Frequency

2.45GHz radio with internal antenna

Range

Short-range radio up to 30 m

Transmit Power

Up to +4dBm

Sensitivity

-96dBm

Sensor

3D accelerometer up to 16g

Outputs / Drivers

Buzzer and stepper motor driver

Inputs / Indicators

Two inputs and one LED

Operating Temperature

-10 C to +60 C

Remote Updates

OTA firmware and configuration file updates

BLE PCB Connector

Battery Type

Standalone 3.6V non-rechargeable battery supply

Battery Connector

Molex 1.50 mm Pico-SPOX vertical PCB header, 2 circuits

PCB Connector Part

Molex 87437-0243

Mating Connector

Molex 87439-0200 with 87421 crimp series

Pinout

Pin 1 battery positive 3.6V; pin 2 ground

Security & Integration

Approvals

ART approved, all-weather certified, Thales certified

Platform Support

Re-Lock system or compatible fleet management platforms

Emergency Function

Manual emergency lock function

Certifications & Origin

ART

Dutch insurance-recognised anti-theft certification (supports EU fleet insurance acceptance)

Cradle to Cradle

Sustainability certified (relevant for municipal RFPs with sustainability mandates)

Patent

Patented digital lock mechanism

Country of Origin

Netherlands (Dutch-engineered and Dutch-assembled)

Connectivity

Bluetooth

Yes

Companion App

Re-Lock system / Key Management Service

Features & Capabilities

Key Features

Bluetooth opening and closing

Replaceable battery (no service-truck charging visits)

Fits tires up to 70 mm (cargo bikes and fat-tire e-bikes)

ART approved (Dutch insurance-recognised anti-theft mark)

Cradle to Cradle certified

All-weather rated

Patented digital lock mechanism

Dutch-engineered and Dutch-assembled

Compatible with Re-Lock or fleet management platforms

73.0 x 30.0 mm standalone BLE PCB

Nordic nRF52832 radio with BLE 4.0 and proprietary 2.4GHz support

Short-range radio range up to 30 m with internal antenna

3D accelerometer up to 16g

Buzzer, two inputs, one LED, and stepper motor driver

Remote OTA firmware and configuration updates

Pros

Simple Bluetooth entry point into the Re-Lock platform
Designed to integrate with compatible fleet systems
Broad fitment claim up to 70 mm tire width
Replaceable battery removes vehicle-power dependence and service-truck charging visits
ART certification supports EU fleet insurance acceptance

Cons

-No GPS on the BLE version
-Public site does not publish detailed battery chemistry or IP rating

Ideal For

Bike sharing fleets

Rental bikes

Standard-width e-bike programs

Compatible Fleet Platforms

Re-Lock API / IoT platform

Re-Lock Key Management Service

Compatible fleet management platforms

Specs taken from the official Re-Lock solutions page on 2026-04-23, then updated from the RE-LOCK Technical Sheets 2026 PCB PDF and product demo video provided in May 2026. Re-Lock advertises a patented digital lock mechanism as a market differentiator. Two ownership models are offered: capex purchase or monthly lease. Known fleet customers include ING, Roetz, Over-Amstel Boerderij, SURE mobility, and Poldar. Nazza micro-mobility software is a named SDK integration partner. Manufacturing origin is the Netherlands. Re-Lock (Chiel Bekker) confirmed commercial terms on 2026-05-13: standard MOQ is 1,000 units (a 100-unit pilot is possible if stock allows); a special 2-sample pilot kit covering one BLE plus one Premium unit is available for €100 with operator-supplied UPS/FedEx account. Lead time is 10 weeks per order (confirmed at quote time; quotes valid 30 days). Premium pricing includes a GSM SIM with 30 MB of data per month for 3 years; bring-your-own SIM has no specific network requirements. US import/certification specifics are still pending forwarder reply. Re-Lock will be unreachable 2026-05-14 through 2026-05-18 for the Dutch national holiday.

About This Product

Re-Lock presents the BLE model as the entry point in its smart-lock range for sharing and rental operations. The official solutions page states that the BLE version opens and closes over Bluetooth, uses a replaceable battery, and fits around almost any tire up to 70 mm.

Re-Lock also emphasizes integration with either its own system or compatible fleet management platforms. That integration-first positioning is why the BLE variant belongs in the catalog despite the relatively light public product page.

The 2026 technical sheets add the underlying BLE PCB details: a compact 73.0 x 30.0 mm board, Nordic nRF52832 radio, BLE 4.0 / proprietary 2.4GHz support, up to 30 m short-range operation, 3D accelerometer, buzzer, stepper motor driver, and OTA firmware/configuration updates.
