SOP - Installing Headset Bolt (MAX PRO)
Installation procedure for the headset bolt on the Segway MAX PRO scooter.
Visual SOP
The following image provides the step-by-step visual instructions for this procedure on the Segway MAX PRO (MAX 2.2) scooter.
Before You Begin
- Ensure the scooter is powered off and in Transport Mode before performing any disassembly
- Have the correct tools and replacement parts ready
- Follow all steps in the sequence shown in the SOP image
- Contact Segway support if you are unsure about any step
